54
Song Playback & Recording
Quick Record
The QUICK RECORD mode, as its name suggests, makes track selection and recording easy by grouping the
accompaniment and manual tracks.
Z Set the Track Modes .................................................................................................................................................................
Use the MANUAL and ACCOMP. LCD [▲/▼]
controls to the select the REC mode for the track(s)
to be recorded, the PLAY mode for the tracks to be
played while recording, or the MUTE mode for
tracks neither to be played or recorded. The PLAY
mode can only be selected for tracks which contain
data.
NOTES
• Note that the SYNCHRO START mode is automatically
engaged when the QUICK RECORD mode is selected, so
be careful not to play the keyboard before you’re ready to
actually start recording, or recording will begin automati-
cally. SYNCHRO START can be disengaged by pressing
the [SYNCHRO START] button.
X Set Up For the Recording ..................................................................................................................................................
Select the required voice(s), select a style, turn
AUTO BASS CHORD on if required (see “NOTES”
below). Set up all parameters as desired for record-
ing. The voices, multi-pad notes, harmony notes,
and accompaniment parts are recorded on the vari-
ous tracks as listed below.
MANUAL
VOICE TRACK
LEAD voice 1
RIGHT 1 voice 2
RIGHT 2 voice 3
LEFT voice 4
MULTI PAD 5
HARMONY 6…8
ACCOMPANIMENT
PART TRACK
RHYTHM 1 9
RHYTHM 2 10
BASS 11
CHORD 1 12
CHORD 2 13
PAD 14
PHRASE 1 15
PHRASE 2 16
NOTES
• If you turn the panel [AUTO BASS CHORD] button on, the
ACCOMP. tracks will automatically be set to the REC
mode.
• If the REC mode is engaged for the ACCOMP. tracks the
panel [AUTO BASS CHORD] button will be turned on
automatically.
