76
Custom Accompaniment
XSelect the Top, Last, and Destination
Measures
Use the TOP and LAST LCD [▲/▼] controls to
specify the first and last measures in the region to be
copied. Use the DEST LCD [▲/▼] control to specify
the top of the measure to which the data is to be
copied.
CCopy the Data
Press the EXECUTE button. The “Completed”
display will appear briefly when the copy operation
has finished. After execution the EXECUTE button
changes to an UNDO button which can be used to
undo the copy operation if the results are not satis-
factory.
■ REMOVE EVENT...........................................................................................................................................................................
This function can be used to remove all occurrences of a specified type of event — VOLUME, PITCH BEND,
or MODULATION — from a specified part.
ZSelect a Part
Use the PART LCD [▲/▼] controls to select the
part from which a type of event is to be removed.
The part name for parts which are being used
unedited from a preset style will appear in small
letters. “*” will appear for parts which contain no
data. Neither can be selected for editing.
XSelect an Event Type
Use the EVENT LCD [▲/▼] controls to select
the type of event to be removed.
NOTES
• MODULATION events cannot be removed from the RHY1
and RHY2 parts.
CRemove the Specified Events
Press the EXECUTE button. “Completed” will
appear on the display briefly when the data has been
removed. After execution the EXECUTE button
changes to an UNDO button which can be used to
undo the copy operation if the results are not satis-
factory.
