68
■ INITIAL EDIT .....................................................................................................................................................................................
Song Playback & Recording
■ SONG DELETE...............................................................................................................................................................................
Allows the initial REVERB DEPTH, CHORUS DEPTH, and DSP EFFECT depth settings for each track to be
edited as required.
ZSelect a Track & Set the Depth Param-
eters
Use the TRACK LCD [▲/▼] control to select a
track, and the REVERB, CHORUS, and DSP EF-
FECT LCD [▲/▼] controls to set the corresponding
depth parameters as required. Only tracks which
contain data can be selected for editing.
XEnter the Edited Data
Press the EXECUTE button. “Executing” will
appear on the display while the data is being up-
dated. After execution the EXECUTE button changes
to an UNDO button which can be used to undo the
initial edit operation if the results are not satisfac-
tory.
This function deletes the specified song file from the disk.
NOTES
• The song currently being recorded cannot be deleted.
• The amount of remaining disk space is displayed in the
upper right corner of the display in approximate kilobytes
while recording or playback is stopped.
ZSelect a Song
Use the SONG LCD [▲/▼] controls to select the
song to be deleted.
XDelete the Song
Press the EXECUTE LCD button. The “Ready to
Delete ********. OK to delete?” confirmation
message will appear (“********” is the song name).
Press YES to delete the song or NO to cancel.
