15
• Do not use water or any other liquid for cleaning.
• Clean the device with a dry cloth or blow through with
compressed air at low pressure
• Do not use any cleaning agents or solvents, they may damage
plastic parts.
• Clean ventilation holes in the motor casing regularly to
prevent device overheating.
• Always store the tool in a dry place, beyond reach of children.
• Store the device with the battery removed.
All defects should be repaired by service workshop authorized
by the manufacturer.
TECHNICAL PARAMETERS
RATED PARAMETERS
Cordless drill 58G022
Parameter Value
Battery voltage 18 V DC
Range of idle rotational speed
gear I 0-350 rpm
gear II 0-1250 rpm
Range of quick release chuck 0,8 - 10 mm
Tool holder 6,35 mm (¼ ‘’)
Torque control range 1–19 + drilling
Max. torque (soft drive) 28 Nm
Max. torque (hard drive) 44 Nm
Protection class III
Weight 1,1 kg
Year of production 2020
58G022 denes type and indication of the device
Graphite Energy+ System Battery
Parameter Value
Battery 58G001 58G004
Battery voltage 18 V DC 18 V DC
Battery type Li-Ion Li-Ion
Battery capacity 2000 mAh 4000 mAh
Ambient temperature range 4
0
C – 40
0
C 4
0
C – 40
0
C
Charging time for charger 58G002 1 h 2 h
Weight 0,400 kg 0,650 kg
Year of production 2020 2020
Graphite Energy+ System Charger
Parameter Value
Charger type
58G002
Supply voltage
230 V AC
Power supply frequency
50 Hz
Charging voltage
22 V DC
Max. charging current
2300 mA
Ambient temperature range
4
0
C – 40
0
C
Charging time of the battery 58G001
1 h
Charging time of the battery 58G004
2 h
Protection class
II
Weight
0,300 kg
Year of production
2020
NOISE LEVEL AND VIBRATION PARAMETERS
Sound pressure Lp
A
= 84 dB(A) K= 3 dB(A)
Sound power Lw
A
= 95 dB(A) K= 3 dB(A)
Vibration acceleration a
h
= 1,552 m/s
2
K= 1,5 m/s
2
Noise and vibration information
Noise produced by the device is defined with: level of produced
sound pressure Lp
A
and level of sound power Lw
A
(where K is
measurement uncertainty). Vibrations produced by the device
are defined with vibration acceleration value a
h
(where K is
measurement uncertainty).
Sound pressure Lp
A
, sound power Lw
A
and vibration acceleration
ah specified in this manual have been measured in accordance
with EN 60745-1:2009+A11:2010. Specified vibration level a
h
can
be used to compare tools and for initial evaluation of exposition
to vibrations.
Specified vibration level is representative for main applications
of the device. When the device is used for other purposes or
with different working tools, the vibration level may change.
Insufficient or too rare maintenance may increase vibration
level. The abovementioned factors may lead to higher exposure
to vibrations during whole working time.
To precisely define exposure to vibrations, include periods
when the device is switched off and when it is switched on
but not used for working. Once all factors have been carefully
considered, total exposition to vibrations may be significantly
lower.
To protect the user from results of exposure to vibrations, use
additional safety measures such as: device and working tool
periodic maintenance, proper hand temperature conditions,
good work organisation.
ENVIRONMENTAL PROTECTION
Electrical equipment must not be disposed o
with household waste and, instead, should be
utilized at appropriate facilities. Information
on utilization can be provided by the product
vendor or the local authorities. Waste electrical
and electronic equipment contains substances
that are not neutral to the natural environment.
Equipment that is not recycled constitutes a
potential hazard to the environment and to
human health.
Li-Ion
Storage batteries/batteries must not be disposed
with domestic waste, put in a re or into the
water. Damaged or used up storage batteries
must be properly recycled in compliance with the
current directive pertaining to disposal of storage
batteries and batteries.
* Right to introduce changes is reserved.
“Grupa Topex Spółka z ograniczoną odpowiedzialnością” Spółka
komandytowa with seat in Warsaw at ul. Pograniczna 2/4 (hereinafter Grupa
Topex) informs, that all copyrights to this instruction (hereinafter Instruction),
including, but not limited to, text, photographies, schemes, drawings
and layout of the instruction, belong to Grupa Topex exclusively and are
protected by laws accordingly to Copyright and Related Rights Act of 4
February 2004 (ustawa o prawie autorskim i prawach pokrewnych, Dz. U. 2006
No 90 item 631 with later ammendments). Copying, processing, publishing,
modifications for commercial purposes of the entire Instruction or its parts
without written permission of Grupa Topex are strictly forbidden and may
cause civil and legal liability.
