Chapter 19 Configuration: Port
GS1900 Series User’s Guide
102
The following table describes the labels in this screen.
19.3.1 The EEE Edit Screen
Use this screen to configure Switch port EEE settings. Click Configuration > Port > EEE > EEE >
Edit to open this screen.
Figure 96 Configuration > Port > EEE > EEE > Edit
The following table describes the labels in this screen.
19.4 PoE
The Switch supports both the IEEE 802.3af Power over Ethernet (PoE) and IEEE 802.3at High Power
over Ethernet (PoE) standards. The Switch is Power Sourcing Equipment (PSE) because it provides
a source of power via its Ethernet ports, and each device that receives power through an Ethernet
port is a Powered Device (PD).
Table 62 Configuration > Port > EEE > EEE
LABEL DESCRIPTION
EEE
Edit Select this check box to configure the properties of a port. Click the Edit button change the
properties of the port.
Port Displays the port index number.
State Displays the port status as enabled or disabled.
Table 63 Configuration > Port > EEE > EEE > Edit
LABEL DESCRIPTION
EEE
Port List Displays the list of port index numbers that are being configured.
State Select Enable to designate the ports as EEE or Disable to not designate them as EEE.
Apply Click Apply to save the changes.
Cancel Click Cancel to discard the changes.
