Chapter 31 Configuration: Management
GS1900 Series User’s Guide
198
31.2.4 The Remote Screen
Use this screen to view the Remote settings. Click Configuration > Management > Syslog >
Remote to open this screen.
Figure 191 Configuration > Management > Syslog > Remote
The following table describes the labels in this screen.
31.2.5 The Remote Add/Modify Screen
Use this screen to configure the Remote settings. Click Configuration > Management > Syslog
> Remote > Add/Modify to open this screen.
Severity Select the severity level of messages to be written to logs.
Apply Click Apply to save the changes.
Cancel Click Cancel to discard the changes.
Table 157 Configuration > Management > Syslog > Local > Add/Modify (continued)
LABEL DESCRIPTION
Table 158 Configuration > Management > Syslog > Remote
LABEL DESCRIPTION
Local
Add Click Add to create a new Remote entry.
Server Displays the server information which includes the server IP address and port number.
Severity Displays the severity level of messages to be written to logs.
Facility Displays the facility designation of the remote entry.
Action
Edit Click Edit to make changes to the entry.
Delete Click Delete to remove the entry.
