Chapter 6 Getting Start
GS1900 Series User’s Guide
42
6.2.1 Wizard
Wizard displays start up, VLAN, QoS, and link aggregation.
For details on Wizard features, see system Chapter 7 on page 52, VLAN Chapter 9 on page 62, QoS
Chapter 28 on page 172, and link aggregation Chapter 11 on page 70.
Start up
In start up, you can set up IP/DNS, set up your username/password, and view finished results.
In order to set up your IP/DNS, please do the following. Click Getting Start > Start up > 1 Step
1 Set up IP to access this screen.
Device Information
System Name This field displays the name used to identify the Switch on any network.
Model Name This field displays the model name of this Switch.
Revision This field displays the hardware revision number of this Switch.
Serial Number This field displays the serial number of this Switch.
MAC Address
Range
This field displays the MAC addresses used by the Switch. Each physical port or wireless
radio has one MAC address. The first MAC address is assigned to the Ethernet LAN port,
the second MAC address is assigned to the first radio, and so on.
Firmware
Version
This field displays the version number and date of the firmware the Switch is currently
running.
System Up Time This field displays how long the Switch has been running since it last restarted or was
turned on.
Current Date/
Time
This field displays the current date and time in the Switch. The format is hh:mm:ss
yyyy-mm-dd .
CPU Usage This field displays the Switch’s recent CPU usage.
Memory Usage This field displays the Switch’s recent memory usage.
Table 10 Getting Start (continued)
LABEL DESCRIPTION
