Chapter 3 Hardware Overview
GS1900 Series User’s Guide
31
Left Amber On The link to a 10/100 Mbps Ethernet network is up.
Blinking The system is transmitting/receiving to/from a 100/1000 Mbps Fiber network.
Green On The link to a 1 Gbps Ethernet network is up.
Blinking The system is transmitting/receiving to/from 1 Gbps Mbps Ethernet network.
Table 4 LED Descriptions (continued)(GS1900-8HP (Revison B1) and GS1900-10HP Only)
LED COLOR STATUS DESCRIPTION
Table 5 LED Descriptions for SFP Port (GS1100-10HP and GS1900-10HP Only)
LED COLOR STATUS DESCRIPTION
Two arrow LEDs for 1G SFP Slots (Fiber Ports)
right/left
arrows
Amber On The link to a 100 Mbps Fiber network is up.
Blinking The system is transmitting/receiving to/from a 100 Mbps Fiber network.
Green On The link to a 1 Gbps Fiber network is up.
Blinking The system is transmitting/receiving to/from 1 Gbps Mbps Fiber network.
