Zyxel GS1900-8HP [138/246] Chapter 23 configuration loop guard

Chapter 23 Configuration: Loop Guard

GS1900 Series User’s Guide

138

Figure 132 Configuration > Loop Guard > Port > Edit

The following table describes the labels in this screen.

Table 98 Configuration > Loop Guard > Port > Edit

LABEL DESCRIPTION

Port

Port List Displays the list of port index numbers to be configured.

State Select Enable to use the Admin Enabled feature.

Action Select the action to take by the Switch.

Apply Click Apply to save the changes.

Cancel Click Cancel to discard the changes.
