Zyxel GS1900-8HP [128/246] Chapter 21 configuration mac table
![Zyxel GS1900-8HP [128/246] Chapter 21 configuration mac table](/views2/1168571/page128/bg80.png)
Chapter 21 Configuration: MAC Table
GS1900 Series User’s Guide
128
Figure 122 Configuration > MAC Table > Dynamic Age
The following table describes the labels in this screen.
Table 88 Configuration > Dynamic Age
LABEL DESCRIPTION
Dynamic MAC Age
Aging Time Enter the aging time of the MAC address. The value can be between 10 and 630 seconds.
Apply Click Apply to save the changes.
Cancel Click Cancel to discard the changes.
