Chapter 29 Configuration: Security
GS1900 Series User’s Guide
189
The following table describes the labels in this screen.
29.5.3 The Port Edit Screen
Use this screen to configure the Port settings.
Click Configuration > Security > DoS > Port > Edit to open this screen.
Figure 181 Configuration > Security > DoS > Port > Edit
The following table describes the labels in this screen.
Table 146 Configuration > Security > DoS > Port
LABEL DESCRIPTION
Port
Edit Select this check box to configure the properties of a port. Click the Edit button change
the properties of the port.
Port Displays the port index value.
State Displays the port’s DoS feature as Enable or Disable.
Table 147 Configuration > Security > DoS > Port > Edit
LABEL DESCRIPTION
Port
Port List Displays the port index value.
State Select Enable to activate the port’s DoS feature.
Apply Click Apply to save the changes.
Cancel Click Cancel to discard the changes.
