Zyxel GS1900-8HP [181/246] Overview

GS1900 Series User’s Guide

181

CHAPTER 29

Configuration: Security

29.1 Overview

This section provides information for Security in Configuration.

29.2 Port Security

29.2.1 The Global Screen

Use this screen to view the Global settings. Click Configuration > Security > Port Security to

open this screen.

Figure 171 Configuration > Security > Port Security

The following table describes the labels in this screen.

29.2.2 The Port Screen

Use this screen to view the Port settings. Click Configuration > Security > Port Security >

Port to open this screen.

Table 137 Configuration > Security > Port Security

LABEL DESCRIPTION

Global

State Select the global security setting to be enabled or disabled.

Apply Click Apply to save the changes.

Cancel Click Cancel to discard the changes.
