Chapter 31 Configuration: Management
GS1900 Series User’s Guide
208
31.5 HTTP/HTTPS
31.5.1 The HTTP Screen
Use this screen to configure the HTTP settings. Click Configuration > Management > HTTP/
HTTPS to open this screen.
Figure 204 Configuration > Management > HTTP/HTTPS
The following table describes the labels in this screen.
31.5.2 The HTTPS Screen
Use this screen to configure the HTTPS settings. Click Configuration > Management > HTTP/
HTTPS > HTTPS to open this screen.
Apply Click Apply to save the changes.
Cancel Click Cancel to discard the changes.
Table 170 Configuration > Management > Error Disable
LABEL DESCRIPTION
Table 171 Configuration > Management > HTTP/HTTPS
LABEL DESCRIPTION
HTTP
State Select the HTTP mode operation.
Possible modes are:
• Enabled: Enable HTTP mode operation.
• Disabled: Disable HTTP mode operation.
Authentication
Method
Select the authentication method from the dropdown list.
Session Timeout Enter the session timeout value. The timeout can be between 0 and 86400 minutes.
Apply Click Apply to save the changes.
Cancel Click Cancel to discard the changes.
