Zyxel GS1900-8HP [195/246] The tacacs add modify screen
![Zyxel GS1900-8HP [195/246] The tacacs add modify screen](/views2/1168571/page195/bgc3.png)
Chapter 30 Configuration: AAA
GS1900 Series User’s Guide
195
30.4.2 The TACACS+ Add/Modify Screen
Use this screen to configure the TACACS+ settings. Click Configuration > AAA > TACACS+ >
Add/Modify to open this screen.
Figure 187 Configuration > AAA > TACACS+ > Add/Modify
The following table describes the labels in this screen.
Table 154 Configuration > AAA > TACACS+ > Add/Modify
LABEL DESCRIPTION
TACACS+
Server Enter the server name(s) as an IP address or a domain name.
Port Enter the port number(s) as a value between 0 and 65535.
Key String Enter the authentication key string: 0 - 63 ASCII alphanumeric characters.
Timeout for
Reply
Enter the number of time outs for replies. The value can be between 1 and 30 seconds.
Priority Select the server priority as High or Low.
Apply Click Apply to save the changes.
Cancel Click Cancel to discard the changes.
