Chapter 27 Configuration: LLDP

GS1900 Series User’s Guide

170

27.2.9 The MED Port Add/Edit Screen

Use this screen to configure the MED Port Edit settings. Click Configuration > LLDP > MED Port

> Edit to open this screen.

Figure 161 Configuration > LLDP > MED Port > Edit

The following table describes the labels in this screen.

Location Displays the Location value.

PoE Displays the PoE value.

Inventory Displays the Inventory value.

Table 126 Configuration > LLDP > MED Port (continued)

LABEL DESCRIPTION

Table 127 Configuration > LLDP > MED Port > Edit

LABEL DESCRIPTION

MED Port

Port List Displays the Port List.

State Select Enable to activate the MED Port feature.

MED Optional

TLVs

Select one or more of the MED Optional TLVs:

• Network Policy

•Location

•PoE PSE

•Inventory

MED Network

Policy

Select one or more of the MED Network Policies in Available and move them to Acting

to activate.
