Chapter 31 Configuration: Management
GS1900 Series User’s Guide
197
31.2.2 The Local Screen
Use this screen to view the Local settings. Click Configuration > Management > Syslog >
Local to open this screen.
Figure 189 Configuration > Management > Syslog > Local
The following table describes the labels in this screen.
31.2.3 The Local Add/Modify Screen
Use this screen to configure the Local settings. Click Configuration > Management > Syslog >
Local > Add/Modify to open this screen.
Figure 190 Configuration > Management > Syslog > Local > Add/Modify
The following table describes the labels in this screen.
Table 156 Configuration > Management > Syslog > Local
LABEL DESCRIPTION
Local
Add Click Add to create a new Local entry.
Target Displays the local storage target for logging messages. The options are Buffered or Flash.
Severity Displays the severity level of messages to be written to logs.
Action
Edit Click Edit to make changes to the entry.
Delete Click Delete to remove the entry.
Table 157 Configuration > Management > Syslog > Local > Add/Modify
LABEL DESCRIPTION
Local Add
Target Select the local storage target for logging messages. The options are Buffered or Flash.
