Chapter 16 System Remote Management
NWA3000-N Series CLI Reference Guide
100
16.7.1 Supported MIBs
The NWA3000-N Series AP supports MIB II that is defined in RFC-1213 and RFC-1215. The
NWA3000-N Series AP also supports private MIBs (ZYXEL-ES-SMI.MIB, ZYXEL-ES-
CAPWAP.MIB, ZYXEL-ES-COMMON.MIB, ZYXEL-ES-HybridAP.MIB, ZYXEL-ES-
ProWLAN.MIB, ZYXEL-ES-RFMGMT.MIB and ZYXEL-ES-WIRELESS.MIB) to collect
information about CPU and memory usage. The focus of the MIBs is to let administrators
collect statistical data and monitor status and performance. You can download the NWA3000-
N Series AP’s MIBs from www.zyxel.com.
16.7.2 SNMP Traps
The NWA3000-N Series AP will send traps to the SNMP manager when any one of the
following events occurs:
16.7.3 SNMP Commands
The following table describes the commands available for SNMP. You must use the
configure terminal command to enter the configuration mode before you can use these
commands.
Table 54 SNMP Traps
OBJECT LABEL OBJECT ID DESCRIPTION
Cold Start 1.3.6.1.6.3.1.1.5.1 This trap is sent when the NWA3000-N Series AP is
turned on or an agent restarts.
linkDown 1.3.6.1.6.3.1.1.5.3 This trap is sent when the Ethernet link is down.
linkUp 1.3.6.1.6.3.1.1.5.4 This trap is sent when the Ethernet link is up.
authenticationFailure 1.3.6.1.6.3.1.1.5.5 This trap is sent when an SNMP request comes from
non-authenticated hosts.
Table 55 Command Summary: SNMP
COMMAND DESCRIPTION
[no] snmp-server version <v2c|v3> Sets the SNMP version support. The no
command removes the SNMP version support.
[no] snmp-server host {fqdn|w.x.y.z}
[community_string]
Sets the domain name or IP address of the host
that receives the SNMP notifications. The
no
command removes the host that receives the
SNMP notifications.
[no] snmp-server enable traps {wireless|capwap} Sets the trap control to receive the wireless/
capwap trap notifications. The no command
removes the wireless/capwap trap notifications.
snmp-server v3user username <username>
authentication <none|MD5|SHA> privacy
<none|DES|AES> privilege <ro|rw>
Sets the SNMPv3 user account and its privilege
of read-only (ro) or read-write (rw) access.
no snmp-server v3user username <username> The no command removes the SNMPv3 user
account.
show snmp status Displays SNMP settings.
show snmp-server v3user status Displays SNMPv3 user status.
