Chapter 7 Wireless LAN Profiles
NWA3000-N Series CLI Reference Guide
57
7.3.1 SSID Profile Example
The following example creates an SSID profile with the name ‘ZyXEL’. It makes the
assumption that both the security profile (SECURITY01) and the MAC filter profile
(MACFILTER01) already exist.
7.4 Security Profile Commands
The following table identifies the values required for many of these commands. Other input
values are discussed with the corresponding commands.
security securityprofile Assigns the specified security profile to this SSID profile.
[no] macfilter macfilterprofile Assigns the specified MAC filtering profile to this SSID
profile. Use the no parameter to remove it.
By default, no MAC filter is assigned.
exit Exits configuration mode for this profile.
Table 21 Command Summary: SSID Profile (continued)
COMMAND DESCRIPTION
Router(config)# wlan-ssid-profile SSID01
Router(config-ssid-radio)# ssid ZyXEL
Router(config-ssid-radio)# qos wmm
Router(config-ssid-radio)# security SECURITY01
Router(config-ssid-radio)# macfilter MACFILTER01
Router(config-ssid-radio)# exit
Router(config)#
Table 22 Input Values for General Security Profile Commands
LABEL DESCRIPTION
security_profile_name The security profile name. You may use 1-31 alphanumeric characters,
underscores (
_), or dashes (-), but the first character cannot be a
number. This value is case-sensitive.
wep_key Sets the WEP key encryption strength. Select either 64bit or 128bit.
wpa_key Sets the WPA/WPA2 pre-shared key in ASCII. You may use 8~63
alphanumeric characters. This value is case-sensitive.
wpa_key_64 Sets the WPA/WPA2 pre-shared key in HEX. You muse use 64
alphanumeric characters.
secret Sets the shared secret used by your network’s RADIUS server.
auth-method The authentication method used by the security profile.
