Chapter 7 Wireless LAN Profiles
NWA3000-N Series CLI Reference Guide
52
[no] ampdu Activates MPDU frame aggregation for this profile. Use
the no parameter to disable it.
Message Protocol Data Unit (MPDU) aggregation collects
Ethernet frames along with their 802.11n headers and
wraps them in a 802.11n MAC header. This method is
useful for increasing bandwidth throughput in
environments that are prone to high error rates.
By default this is enabled.
limit-ampdu < 100..65535> Sets the maximum frame size to be aggregated.
By default this is 50000.
subframe-ampdu <2..64> Sets the maximum number of frames to be aggregated
each time.
By default this is 32.
[no] amsdu Activates MPDU frame aggregation for this profile. Use
the no parameter to disable it.
Mac Service Data Unit (MSDU) aggregation collects
Ethernet frames without any of their 802.11n headers and
wraps the header-less payload in a single 802.11n MAC
header. This method is useful for increasing bandwidth
throughput. It is also more efficient than A-MPDU except
in environments that are prone to high error rates.
By default this is enabled.
limit-amsdu <2290..4096> Sets the maximum frame size to be aggregated.
The default is 4096.
[no] block-ack Makes block-ack active or inactive. Use the no
parameter to disable it.
ch-width wlan_htcw Sets the channel width for this profile.
guard-interval wlan_htgi Sets the guard interval for this profile.
The default for this is short.
2g-basic-speed {disable |
wlan_2g_basic_speed}
Disables or sets the 2.4 GHz basic band rates.
The default is 1.0 2.0 5.5 11.0.
2g-support-speed {disable |
wlan_2g_support_speed}
Disables or sets the 2.4 GHz support rate.
The default is 1.0~54.0.
2g-mcs-speed {disable |
wlan_mcs_speed}
Disables or sets the 2.4 GHz HT MCS rate.
The default is 0~15.
5g-basic-speed {disable |
wlan_5g_basic_speed}
Disables or sets the 5 GHz basic band rate.
The default is 6.0 12.0 24.0.
5g-support-speed {disable |
wlan_5g_support_speed}
Disables or sets the 5 GHz support rate.
The default is 6.0~54.0.
5g-mcs-speed {disable |
wlan_mcs_speed}
Disables or sets the 5 GHz HT MCS rate.
The default is 0~15.
tx-mask chain_mask Sets the outgoing chain mask.
rx-mask chain_mask Sets the incoming chain mask.
[no] htprotection Activates HT protection for this profile. Use the no
parameter to disable it.
By default, this is disabled.
output-power wlan_power Sets the output power for the radio in this profile.
The default is 100%.
Table 19 Command Summary: Radio Profile (continued)
COMMAND DESCRIPTION
