Chapter 2 User and Privilege Modes
NWA3000-N Series CLI Reference Guide
27
2.1.1 Debug Commands
Debug commands marked with an asterisk (*) are not available when the debug flag is on and
are for ZyXEL service personnel use only. The debug commands follow a syntax that is
Linux-based, so if there is a Linux equivalent, it is displayed in this chapter for your reference.
You must know a command listed here well before you use it. Otherwise, it may cause
undesired results.
Table 6 Debug Commands
COMMAND SYNTAX DESCRIPTION LINUX COMMAND EQUIVALENT
debug app Application patrol debug command
debug app show l7protocol
(*)
Shows app patrol protocol list > cat /etc/l7_protocols/
protocol.list
debug ca (*) Certificate debug commands
debug device-ha (*) Device HA debug commands
debug gui (*) GUI cgi related debug commands
debug gui (*) Web Configurator related debug
commands
debug hardware (*) Hardware debug commands
debug interface Interface debug commands
debug interface ifconfig
[interface]
Shows system interfaces detail > ifconfig [interface]
debug ip dns DNS debug commands
debug logging System logging debug commands
debug manufacture Manufacturing related debug
commands
debug network arpignore (*) Enable/Display the ignoring of ARP
responses for interfaces which don't
own the IP address
cat /proc/sys/net/ipv4/
conf/*/arp_ignore
debug policy-route (*) Policy route debug command
debug [cmdexec|corefile|ip
|kernel|mac-id-
rewrite|observer|switch
|system|zyinetpkt] (*)
ZLD internal debug commands
