Chapter 11 Wireless Load Balancing
NWA3000-N Series CLI Reference Guide
73
11.2.1 Wireless Load Balancing Examples
The following example shows you how to configure AP load balancing in "by station" mode.
The maximum number of stations is set to 1.
The following example shows you how to configure AP load balancing in "by traffic" mode.
The traffic level is set to low, and "disassociate station" is enabled.
show load-balancing loading Displays the loading status per radio (underload / balance
/ overload) when you enable the load balancing fuction.
[no] load-balancing activate Enables load balancing. Use the no parameter to disable
it.
Table 34 Command Summary: Load Balancing (continued)
COMMAND DESCRIPTION
Router(config)# load-balancing mode station
Router(config)# load-balancing max sta 1
Router(config)# show load-balancing config
load balancing config:
Activate: yes
Kickout: no
Mode: station
Max-sta: 1
Traffic-level: high
Alpha: 5
Beta: 10
Sigma: 60
Timeout: 20
LIInterval: 10
KickoutInterval: 20
Router(config)# load-balancing mode traffic
Router(config)# load-balancing traffic level low
Router(config)# load-balancing kickout
Router(config)# show load-balancing config
load balancing config:
Activate: yes
Kickout: yes
Mode: traffic
Max-sta: 1
Traffic-level: low
Alpha: 5
Beta: 10
Sigma: 60
Timeout: 20
LIInterval: 10
KickoutInterval: 20
