Chapter 6 AP Management
NWA3000-N Series CLI Reference Guide
47
6.3 AP Management Client Commands
The following table describes the commands available for configuring CAPWAP client APs.
You must use the
configure terminal command to enter the configuration mode before
you can use these commands.
6.3.1 AP Management Client Commands Example
The following example shows you how to configure the interface of an AP, connect to the
controller NWA3000-N Series AP, and check the connecting status.
Table 17 Command Summary: AP Client Commands
COMMAND DESCRIPTION
capwap ap vlan ip address { ip subnet_mask
| dhcp }
Sets the managed AP’s address or sets it to use DHCP.
capwap ap vlan [no] ip gateway ip Adds the managed AP’s gateway address. The no
command removes the gateway.
capwap ap vlan vlan-id <1..4094> [tag |
untag]
Sets the managed AP’s VLAN ID and tagging setting.
capwap ap ac-ip { primary ip secondary ip
| auto }
Sets the controller’s address or sets it to use DHCP
option 138.
show capwap ap info Displays information about the managed AP’s wireless
usage.
show capwap ap discovery-type Displays how the managed AP gets its IP address.
show capwap ap ac-ip Displays the controller’s IP address
Router# configure terminal
Router(config)# show capwap_wtp ap discovery-type
Discovery type : Broadcast
Router(config)# capwap ap vlan ip address 192.168.1.37 255.255.255.0
Router(config)# capwap ap vlan ip gateway 192.168.1.32
outer(config)# capwap ap ac-ip 192.168.1.1 192.168.1.2
Router(config)# show capwap ap discovery-type
Discovery type : Static AC IP
Router(config)# show capwap ap ac-ip
AC IP: 192.168.1.1 192.168.1.2
Router(config)# exit
Router# show capwap ap info
SM-State RUN(8)
msg-buf-usage 0/10 (Usage/Max)
capwap-version 10118
Radio Number 1/4 (Usage/Max)
BSS Number 8/8 (Usage/Max)
IANA ID 037a
Description AP-0013499999FF
