NWA3000-N Series CLI Reference Guide
35
CHAPTER 5
Interfaces
This chapter shows you how to use interface-related commands.
5.1 Interface Overview
In general, an interface has the following characteristics.
• An interface is a logical entity through which (layer-3) packets pass.
• An interface is bound to a physical port or another interface.
• Many interfaces can share the same physical port.
Some characteristics do not apply to some types of interfaces.
5.1.1 Types of Interfaces
You can create several types of interfaces in the NWA3000-N Series AP:
• Ethernet interfaces are the foundation for defining other interfaces and network policies.
• VLAN interfaces receive and send tagged frames. The NWA3000-N Series AP
automatically adds or removes the tags as needed.
5.2 Interface General Commands Summary
The following table identifies the values required for many of these commands. Other input
values are discussed with the corresponding commands.
The following sections introduce commands that are supported by several types of interfaces.
Table 9 Input Values for General Interface Commands
LABEL DESCRIPTION
interface_name The name of the interface.
Ethernet interface: gex, x = 1 - N, where N equals the highest numbered Ethernet
interface for your NWA3000-N Series AP model.
VLAN interface: vlanx, x = 0 - 511
domain_name Fully-qualified domain name. You may up to 254 alphanumeric characters,
dashes (-), or periods (.), but the first character cannot be a period.
