Chapter 17 File Manager
NWA3000-N Series CLI Reference Guide
110
Figure 14 FTP Configuration File Download Example
17.7 NWA3000-N Series AP File Usage at Startup
The NWA3000-N Series AP uses the following files at system startup.
Figure 15 NWA3000-N Series AP File Usage at Startup
1 The boot module performs a basic hardware test. You cannot restore the boot module if it
is damaged. The boot module also checks and loads the recovery image. The NWA3000-
N Series AP notifies you if the recovery image is damaged.
2 The recovery image checks and loads the firmware. The NWA3000-N Series AP notifies
you if the firmware is damaged.
C:\>ftp 192.168.1.1
Connected to 192.168.1.1.
220 FTP Server [192.168.1.1]
User (192.168.1.1:(none)): admin
331 Password required for admin.
Password:
230 User admin logged in.
ftp> bin
200 Type set to I
ftp> cd conf
250 CWD command successful
ftp> get today.conf current.conf
200 PORT command successful
150 Opening BINARY mode data connection for conf/today.conf
(20220 bytes)
226 Transfer complete.
ftp: 20220 bytes received in 0.03Seconds 652.26Kbytes/sec.
1. Boot Module
2. Recovery Image
3. Firmware
