Chapter 5 Interfaces
NWA3000-N Series CLI Reference Guide
40
The following example shows LAN settings.
The following example shows each port’s type of cable connection.
5.5 VLAN Interface Specific Commands
A Virtual Local Area Network (VLAN) divides a physical network into multiple logical
networks. The standard is defined in IEEE 802.1q.
In the NWA3000-N Series AP, each VLAN is called a VLAN interface. As a router, the
NWA3000-N Series AP routes traffic between VLAN interfaces, but it does not route traffic
within a VLAN interface.
" vlan0 is the default VLAN interface. It cannot be deleted and its VID cannot
changed.
Otherwise, VLAN interfaces are similar to other interfaces in many ways. They have an IP
address, subnet mask, and gateway used to make routing decisions. They restrict bandwidth
and packet size. They can verify the gateway is available.
The following table identifies the values required for many of these commands. Other input
values are discussed with the corresponding commands.
Router(config)# show manager vlan
Management Interface:
VLAN ID: 100
VLAN Tag: untag
IP Status: static
IP Address: 192.168.1.2
Mask: 255.255.255.0
Gateway: 0.0.0.0
Router(config)# show port type
Port Type
===========================================================================
1 Copper
Table 13 Input Values for VLAN Interface Commands
LABEL DESCRIPTION
config_interface The VLAN interlace name. You may use 0-511 alphanumeric
characters, underscores (
_), or dashes (-), but the first character cannot
be a number. This value is case-sensitive.
gateway The gateway IP address of the interface. Enter a standard IPv4 IP
address (for example, 127.0.0.1).
addr The network mask IP address. Enter a standard IPv4 IP address.
