![Zyxel NWA3550-N [37/152] Chapter 5 interfaces](/views2/1169192/page37/bg25.png)
Chapter 5 Interfaces
NWA3000-N Series CLI Reference Guide
37
[no] mss <536..1460> Specifies the maximum segment size (MSS) the
interface is to use. MSS is the largest amount of
data, specified in bytes, that the interface can
handle in a single, unfragmented piece. The
no
command has the interface use its default MSS.
[no] mtu <576..1500> Specifies the Maximum Transmission Unit, which is
the maximum number of bytes in each packet
moving through this interface. The NWA3000-N
Series AP divides larger packets into smaller
fragments. The
no command resets the MTU to
1500.
[no] shutdown Deactivates the specified interface. The
no
command activates it.
traffic-prioritize {tcp-ack|dns} bandwidth
<0..1048576> priority <1..7> [maximize-
bandwidth-usage];
Applies traffic priority when the interface sends
TCP-ACK traffic, or traffic for resolving domain
names. It also sets how much bandwidth the traffic
can use and can turn on maximize bandwidth
usage.
traffic-prioritize {tcp-ack|dns}
deactivate
Turns off traffic priority settings for when the
interface sends the specified type of traffic.
[no] upstream <0..1048576> Specifies the upstream bandwidth for the specified
interface. The
no command sets the upstream
bandwidth to 1048576.
interface manager ap vlan ip address [ ip
subnet_mask | dhcp]
Sets the manager IP address.
interface manager ap vlan [no] ip gateway ip Sets the manager gateway address. The
no
command removes the gateway.
interface manager ap vlan vlan-id <1..4094>
[tag | untag]
Sets the manager VLAN ID and tagging setting.
interface send statistics interval <15..3600> Sets how often the NWA3000-N Series AP sends
interface statistics to external servers. For
example, a syslog server.
show interface-name Displays all Ethernet interface system name and
user-defined name mappings.
interface-name {bridge_interface}
user_defined_name
Specifies a name for a bridge interface. It can use
alphanumeric characters, hyphens, and
underscores, and it can be up to 11 characters
long.
ethernet_interface: This must be the system
name of a bridge interface. Use the show
interface-name command to see the system
name of interfaces.
user_defined_name:
• This name cannot be one of the follows:
"ethernet", "ppp", "vlan", "bridge", "virtual",
"wlan", "cellular", "aux", "tunnel", "status",
"summary", "all"
• This name cannot begin with one of the follows
either: "ge", "ppp", "vlan", "wlan-", "br",
"cellular", "aux", "tunnel".
interface-rename old_user_defined_name
new_user_defined_name
Modifies the user-defined name of an Ethernet
interface.
Table 10 interface General Commands: Basic Properties and IP Address Assignment (continued)
COMMAND DESCRIPTION
