Chapter 7 Wireless LAN Profiles
NWA3000-N Series CLI Reference Guide
56
The following table describes the commands available for SSID profile managment. You must
use the
configure terminal command to enter the configuration mode before you can use
these commands.
wlan_qos Sets the type of QoS the SSID should use.
disable: Turns off QoS for this SSID.
wmm: Turns on QoS for this SSID. It automatically assigns Access
Categories to packets as the device inspects them in transit.
wmm_be: Assigns the “best effort” Access Category to all traffic moving
through the SSID regardless of origin.
wmm_bk: Assigns the “background” Access Category to all traffic
moving through the SSID regardless of origin.
wmm_vi: Assigns the “video” Access Category to all traffic moving
through the SSID regardless of origin.
wmm_vo: Assigns the “voice” Access Category to all traffic moving
through the SSID regardless of origin.
securityprofile Assigns an existing security profile to the SSID profile. You may use 1-
31 alphanumeric characters, underscores (
_), or dashes (-), but the first
character cannot be a number. This value is case-sensitive.
macfilterprofile Assigns an existing MAC filter profile to the SSID profile. You may use
1-31 alphanumeric characters, underscores (
_), or dashes (-), but the
first character cannot be a number. This value is case-sensitive.
description2 Sets the description of the profile. You may use up to 60 alphanumeric
characters, underscores (
_), or dashes (-). This value is case-sensitive.
Table 20 Input Values for General SSID Profile Commands (continued)
LABEL DESCRIPTION
Table 21 Command Summary: SSID Profile
COMMAND DESCRIPTION
show wlan-ssid-profile {all |
[ssid_profile_name]}
Displays the SSID profile(s).
all: Displays all profiles for the selected operating mode.
ssid_profile_name: Displays the specified profile for
the selected operating mode.
wlan-ssid-profile rename
ssid_profile_name1 ssid_profile_name2
Gives an existing SSID profile (ssid_profile_name1)
a new name (ssid_profile_name2).
[no] wlan-ssid-profile ssid_profile_name Enters configuration mode for the specified SSID profile.
Use the no parameter to remove the specified profile.
[no] block-intra Enables intra-BSSID traffic blocking. Use the no
parameter to disable it in this profile.
By default this is disabled.
[no] hide Prevents the SSID from being publicly broadcast. Use the
no parameter to re-enable public broadcast of the SSID
in this profile.
By default this is disabled.
ssid Sets the SSID. This is the name visible on the network to
wireless clients. Enter up to 32 characters, spaces and
underscores are allowed.
The default SSID is ‘ZyXEL’.
qos wlan_qos Sets the type of QoS used by this SSID.
[no] vlan-id <1..4094> Applies to each SSID profile. If the VLAN ID is equal to
the AP’s native VLAN ID then traffic originating from the
SSID is not tagged.
The default VLAN ID is 1.
