Chapter 6 AP Management
NWA3000-N Series CLI Reference Guide
46
6.2.1 AP Management Commands Example
The following example shows you how to add an AP to the management list, and then edit it.
Router# show capwap ap wait-list
index: 1
IP: 192.168.1.35, MAC: 00:11:11:11:11:FE
Model: NWA3160-N, Description: AP-00:11:11:11:11:FE
index: 2
IP: 192.168.1.36, MAC: 00:19:CB:00:BB:03
Model: NWA3160-N, Description: AP-00:19:CB:00:BB:03
Router# configure terminal
Router(config)# capwap ap add 00:19:CB:00:BB:03
Router(config)# capwap ap 00:19:CB:00:BB:03
Router(AP 00:19:CB:00:BB:03)# slot1 ap-profile approf01
Router(AP 00:19:CB:00:BB:03)# exit
Router(config)# show capwap ap all
index: 1
Status: On-Line, Loading: Balanced
IP: 192.168.1.10, MAC: 00:19:CB:00:BB:03
Description: AP-0019CB00BB03, Model: NWA5160N
R1mode: AP, R1Prof: approf01
Station: 0, RadioNum: 1
VLAN ID: 1, Tag: no
Tunnel mode = 0
Firmware version = 220AAt0b1
Router> show capwap ap 00:19:CB:00:BB:03 slot1 detail
index: 1
SSID: ZyXEL, BSSID: 00:19:CB:00:BB:04
SecMode: NONE, Forward Mode: Local Bridge, Vlan: 1
index: 2
SSID: test, BSSID: 06:19:CB:00:BB:04
SecMode: NONE, Forward Mode: Local Bridge, Vlan: 1
Router(config)# show capwap ap all statistics
index: 1
AP MAC: 00:19:CB:00:BB:03
Radio: R1, OP Mode: AP
Profile: APprofile01, MAC: 00:19:CB:00:BB:04
Description: AP- 00:19:CB:00:BB:03, Model: NWA3160-N
Band: 2.4GHz, Channel: 11
RxPkt: 123456, TxPkt: 123458
RxFCS: 123456, TxRetry: 123458
index: 2
AP MAC: 00:19:CB:AA:AA:03
Radio: R1, OP Mode: AP
Profile: APprofile01, MAC: 00:19:CB:AA:AA:04
Description: AP- 00:19:CB:AA:AA:03, Model: NWA3160-N
Band: 5GHz, Channel: 161/157
RxPkt: 123456, TxPkt: 123458
RxFCS: 123456, TxRetry: 123458
