Chapter 6 AP Management
NWA3000-N Series CLI Reference Guide
44
6.2 AP Management Commands
The following table identifies the values required for many of these commands. Other input
values are discussed with the corresponding commands.
The following table describes the commands available for AP managment. You must use the
configure terminal command to enter the configuration mode before you can use these
commands.
Table 15 Input Values for General AP Management Commands
LABEL DESCRIPTION
ap_mac The Ethernet MAC address of the managed AP. Enter 6 hexadecimal pairs
separated by colons. You can use 0-9, a-z and A-Z.
slot_name The slot name for the AP’s on-board wireless LAN card. Use either slot1 or
slot2. (Not all NWA3000-N Series APs support 2 radio slots.)
profile_name The wireless LAN radio profile name. You may use 1-31 alphanumeric
characters, underscores(
_), or dashes (-), but the first character cannot be a
number. This value is case-sensitive.
ap_description The AP description. This is strictly used for reference purposes and has no
effect on any other settings. You may use 1-31 alphanumeric characters,
underscores(
_), or dashes (-), but the first character cannot be a number. This
value is case-sensitive.
sta_mac The Ethernet MAC address of the managed station (or wireless client). Enter 6
hexadecimal pairs separated by colons. You can use 0-9, a-z and A-Z.
Table 16 Command Summary: AP Management
COMMAND DESCRIPTION
capwap manual-add { enable | disable } Allows the NWA3000-N Series AP to either automatically
add new APs to the network (disable) or wait until you
manually confirm them (enable).
show capwap manual-add Displays the current manual add option.
capwap ap add ap_mac Adds the specified AP to the NWA3000-N Series AP for
management. If manual add is disabled, this command
can still be used; if you add an AP before it connects to
the network, then this command simply preconfigures the
management list with that AP’s information.
capwap ap kick { all | ap_mac } Removes the specified AP (ap_mac) or all connected
APs (all) from the management list. Doing this removes
the AP(s) from the management list.
If the NWA3000-N Series AP is set to automatically add
new APs to the AP management list, then any kicked APs
are added back to the management list as soon as they
reconnect.
capwap ap reboot ap_mac Forces the specified AP (ap_mac) to restart. Doing this
severs the connections of all associated stations.
capwap ap ap_mac Enters the sub-command mode for the specified AP.
slot_name ap-profile profile_name Sets the radio (slot_name) to AP mode and assigns a
created profile to the radio.
slot_name monitor-profile
profile_name
Sets the specified radio (slot_name) to monitor mode
and assigns a created profile to the radio.
description ap_description Sets the description for the specified AP.
