Chapter 7 Wireless LAN Profiles
NWA3000-N Series CLI Reference Guide
51
role {ap | ap-wds | wds} Sets the profile’s wireless LAN radio operating mode.
Use ap to have the radio function as an access
point with one or more BSSIDs.
Use ap-wds to have the radio function as an access
point and bridge simultaneously.
Use wds to have the radio function as a wireless network
bridge / repeater and establish wireless links with other
APs.
band wlan_band Sets the radio band for this profile.
2g-channel wireless_channel_2g Sets the broadcast band for this profile in the 2.4 Ghz
frequency range. The default is 6.
5g-channel wireless_channel_5g Sets the broadcast band for this profile in the 5 GHz
frequency range.
[no] disable-dfs-switch Makes the DFS switch active or inactive. By default this is
inactive.
[no] ctsrts <0..2347> Sets or removes the RTS/CTS value for this profile.
Use RTS/CTS to reduce data collisions on the wireless
network if you have wireless clients that are associated
with the same AP but out of range of one another. When
enabled, a wireless client sends an RTS (Request To
Send) and then waits for a CTS (Clear To Send) before it
transmits. This stops wireless clients from transmitting
packets at the same time (and causing data collisions).
A wireless client sends an RTS for all packets larger than
the number (of bytes) that you enter here. Set the RTS/
CTS equal to or higher than the fragmentation threshold
to turn RTS/CTS off.
The default is 2347.
[no] frag <256..2346> Sets or removes the fragmentation value for this profile.
The threshold (number of bytes) for the fragmentation
boundary for directed messages. It is the maximum data
fragment size that can be sent.
The default is 2346.
dtim-period <1..255> Sets the DTIM period for this profile.
Delivery Traffic Indication Message (DTIM) is the time
period after which broadcast and multicast packets are
transmitted to mobile clients in the Active Power
Management mode. A high DTIM value can cause clients
to lose connectivity with the network. This value can be
set from 1 to 255.
The default is 1.
beacon-interval <40..1000> Sets the beacon interval for this profile.
When a wirelessly networked device sends a beacon, it
includes with it a beacon interval. This specifies the time
period before the device sends the beacon again. The
interval tells receiving devices on the network how long
they can wait in low-power mode before waking up to
handle the beacon. This value can be set from 40ms to
1000ms. A high value helps save current consumption of
the access point.
The default is 100.
Table 19 Command Summary: Radio Profile (continued)
COMMAND DESCRIPTION
