Chapter 16 System Remote Management
NWA3000-N Series CLI Reference Guide
96
16.2.1 HTTP/HTTPS Command Examples
This command sets an authentication method used by the HTTP/HTTPS server to authenticate
the client(s).
[no] ip http secure-port <1..65535> Sets the HTTPS service port number. The no
command resets the HTTPS service port number
to the factory default (443).
[no] ip http secure-server Enables HTTPS access to the NWA3000-N
Series AP web configurator. The
no command
disables HTTPS access to the NWA3000-N
Series AP web configurator.
[no] ip http secure-server auth-client Sets the client to authenticate itself to the HTTPS
server. The
no command sets the client not to
authenticate itself to the HTTPS server.
[no] ip http secure-server cert certificate_name Specifies a certificate used by the HTTPS server.
The no command resets the certificate used by
the HTTPS server to the factory default
(default).
certificate_name: The name of the
certificate. You can use up to 31 alphanumeric
and ;‘~!@#$%^&()_+[]{}’,.=-
characters.
[no] ip http secure-server force-redirect Redirects all HTTP connection requests to a
HTTPS URL. The
no command disables
forwarding HTTP connection requests to a
HTTPS URL.
ip http secure-server cipher-suite
{cipher_algorithm} [cipher_algorithm]
[cipher_algorithm] [cipher_algorithm]
Sets the encryption algorithms (up to four) that
the NWA3000-N Series AP uses for the SSL in
HTTPS connections and the sequence in which it
uses them. The cipher_algorithm can be
any of the following.
rc4: RC4 (RC4 may impact the NWA3000-N
Series AP’s CPU performance since the
NWA3000-N Series AP’s encryption accelerator
does not support it).
aes: AES
des: DES
3des: Triple DES.
no ip http secure-server cipher-suite
{cipher_algorithm}
Has the NWA3000-N Series AP not use the
specified encryption algorithm for the SSL in
HTTPS connections.
[no] ip http server Allows HTTP access to the NWA3000-N Series
AP web configurator. The
no command disables
HTTP access to the NWA3000-N Series AP web
configurator.
show ip http server status Displays HTTP settings.
show ip http server secure status Displays HTTPS settings.
Table 50 Command Summary: HTTP/HTTPS (continued)
COMMAND DESCRIPTION
Router# configure terminal
Router(config)# ip http authentication Example
