Chapter 2 User and Privilege Modes
NWA3000-N Series CLI Reference Guide
26
Subsequent chapters in this guide describe the configuration commands. User/privilege mode
commands that are also configuration commands (for example, ‘show’) are described in more
detail in the related configuration command chapter.
diag-info P Has the NWA3000-N Series AP create a new diagnostic file.
dir P Lists files in a directory.
disable U/P Goes from privilege mode to user mode
enable U/P Goes from user mode to privilege mode
exit U/P Goes to a previous mode or logs out.
htm U/P Goes to htm (hardware test module) mode for testing hardware components. You
may need to use the htm commands if your customer support Engineer asks you
to during troubleshooting.
Note: These commands are for ZyXEL’s internal manufacturing
process.
interface U/P Dials or disconnects an interface.
no packet-trace U/P Turns of packet tracing.
nslookup U/P Resolves an IP address to a host name and vice-versa.
packet-trace U/P Performs a packet trace.
ping U/P Pings an IP address or host name.
psm U/P Goes to psm (product support module) mode for setting product parameters. You
may need to use the htm commands if your customer support Engineer asks you
to during troubleshooting.
Note: These commands are for ZyXEL’s internal manufacturing
process.
reboot P Restarts the device.
release P Releases DHCP information from an interface.
rename P Renames a configuration file.
renew P Renews DHCP information for an interface.
run P Runs a script.
setenv U/P Turns stop-on-error on (terminates booting if an error is found in a configuration
file) or off (ignores configuration file errors and continues booting).
show U/P Displays command statistics. See the associated command chapter in this guide.
shutdown P Writes all d data to disk and stops the system processes. It does not turn off the
power.
telnet U/P Establishes a connection to the TCP port number 23 of the specified host name or
IP address.
test aaa U/P Tests whether the specified user name can be successfully authenticated by an
external authentication server.
traceroute P Traces the route to the specified host name or IP address.
write P Saves the current configuration to the NWA3000-N Series AP. All unsaved
changes are lost after the NWA3000-N Series AP restarts.
Table 5 User (U) and Privilege (P) Mode Commands (continued)
COMMAND MODE DESCRIPTION
