Chapter 5 Interfaces
NWA3000-N Series CLI Reference Guide
36
5.2.1 Basic Interface Properties and IP Address Commands
This table lists basic properties and IP address commands.
Table 10 interface General Commands: Basic Properties and IP Address Assignment
COMMAND DESCRIPTION
manager ap vlan vlan-id <1..4094> <tag|untag> When the NWA3000-N Series AP is in standalone
or controller mode, this sets the AP’s VLAN
identification number and sets it to send tagged or
untagged packets.
capwap ap vlan vlan-id <1..4094> <tag|untag> When the NWA3000-N Series AP is in managed
mode, this sets the AP’s VLAN identification
number and sets it to send tagged or untagged
packets.
show interface {ethernet | vlan} status Displays the connection status of the specified type
of interfaces.
show interface {interface_name | ethernet |
vlan | all}
Displays information about the specified interface,
specified type of interfaces, or all interfaces.
show interface send statistics interval Displays the interval for how often the NWA3000-N
Series AP refreshes the sent packet statistics for
the interfaces.
show interface summary all Displays basic information about the interfaces.
show interface summary all status Displays the connection status of the interfaces.
[no] interface interface_name Creates the specified interface if necessary and
enters sub-command mode. The
no command
deletes the specified interface.
[no] description description Specifies the description for the specified interface.
The
no command clears the description.
description: You can use alphanumeric and
()+/:=?!*#@$_%- characters, and it can be up
to 60 characters long.
[no] downstream <0..1048576> This is reserved for future use.
Specifies the downstream bandwidth for the
specified interface. The
no command sets the
downstream bandwidth to 1048576.
exit Leaves the sub-command mode.
[no] ip address dhcp Makes the specified interface a DHCP client; the
DHCP server gives the specified interface its IP
address, subnet mask, and gateway. The
no
command makes the IP address static IP address
for the specified interface. (See the next command
to set this IP address.)
[no] ip address ip subnet_mask Assigns the specified IP address and subnet mask
to the specified interface. The
no command clears
the IP address and the subnet mask.
[no] ip gateway ip Adds the specified gateway using the specified
interface. The no command removes the gateway.
ip gateway ip metric <0..15> Sets the priority (relative to every gateway on every
interface) for the specified gateway. The lower the
number, the higher the priority.
[no] metric <0..15> Sets the interface’s priority relative to other
interfaces. The lower the number, the higher the
priority.
