Chapter 10 Dynamic Channel Selection
NWA3000-N Series CLI Reference Guide
68
10.2.1 DCS Examples
This example creates a DCS configuration.
dcs client-aware {enable|disable} When enabled, this ensures that an AP will not change
channels as long as a client is connected to it. If disabled,
the AP may change channels regardless of whether it has
clients connected to it or not.
dcs channel-deployment {3-channel|4-
channel}
Use this when you set the dcs-2g-method to manual.
Sets either a 3-channel deployment or a 4-channel
deployment.
In a 3-channel deployment, the AP running the scan
alternates between the following channels: 1, 6, and 11.
In a 4-channel deployment, the AP running the scan
alternates between the following channels: 1, 4, 7, and 11
(FCC) or 1, 5, 9, and 13 (ETSI).
Set the option that is applicable to your region. (Channel
deployment may be regulated differently between
countries and locales.)
dcs dcs-2g-method {auto|manual} Sets how you specify the channels the AP switches
between for 2.4 GHz operation.
dcs 2g-selected-channel wlan_channel_2g Sets a 2.4 GHz channel to use (1~14).
dcs dcs-5g-method {auto|manual} Sets how you specify the channels the AP switches
between for 5 GHz operation.
dcs 5g-selected-channel wlan_channel_5g Sets a 5 GHz channel to use
(36|40|44|48|52|56|60|64|100|104|108|112|116|120|124|1
28|132|136|140|149|153|157|161|165).
dcs dfs-aware {enable|disable} Enable this to allow an AP to avoid phase DFS channels
below the 5 GHz spectrum.
show dcs config Displays the current DCS configuration.
Table 33 Command Summary: DCS (continued)
COMMAND DESCRIPTION
Router(config)# dcs time-interval 720
Router(config)# dcs sensitivity-level high
Router(config)# dcs client-aware enable
Router(config)# dcs dcs-2g-method auto
Router(config)# dcs channel-deployment 3-channel
Router(config)# dcs 2g-selected-channel 1
Router(config)# dcs dcs-5g-method manual
Router(config)# dcs 5g-selected-channel 36
Router(config)# dcs dfs-aware enable
