NWA3000-N Series CLI Reference Guide
29
CHAPTER 3
Object Reference
This chapter describes how to use object reference commands.
3.1 Object Reference Commands
The object reference commands are used to see which configuration settings reference a
specific object. You can use this table when you want to delete an object because you have to
remove references to the object first.
Table 7 show reference Commands
COMMAND DESCRIPTION
show reference object username
[username]
Displays which configuration settings reference the
specified user object.
show reference object aaa
authentication [default |
profile]
Displays which configuration settings reference the
specified AAA authentication object.
show reference object ca
category {local|remote}
[cert_name]
Displays which configuration settings reference the
specified authentication method object.
show reference object [wlan-
radio-profile]
Displays the specified radio profile object.
show reference object [wlan-
monitor-profile]
Displays the specified monitor profile object.
show reference object [wlan-
ssid-profile]
Displays the specified SSID profile object.
show reference object [wlan-
security-profile]
Displays the specified security profile object.
show reference object [wlan-
macfilter-profile]
Displays the specified macfilter profile object.
