Chapter 16 System Remote Management
NWA3000-N Series CLI Reference Guide
97
This following example sets a certificate named MyCert used by the HTTPS server to
authenticate itself to the SSL client.
16.3 SSH
Unlike Telnet or FTP, which transmit data in clear text, SSH (Secure Shell) is a secure
communication protocol that combines authentication and data encryption to provide secure
encrypted communication between two hosts over an unsecured network.
16.3.1 SSH Implementation on the NWA3000-N Series AP
Your NWA3000-N Series AP supports SSH versions 1 and 2 using RSA authentication and
four encryption methods (AES, 3DES, Archfour, and Blowfish). The SSH server is
implemented on the NWA3000-N Series AP for remote management on port 22 (by default).
16.3.2 Requirements for Using SSH
You must install an SSH client program on a client computer (Windows or Linux operating
system) that is used to connect to the NWA3000-N Series AP over SSH.
16.3.3 SSH Commands
The following table describes the commands available for SSH. You must use the configure
terminal
command to enter the configuration mode before you can use these commands.
Router# configure terminal
Router(config)# ip http secure-server cert MyCert
Table 51 Command Summary: SSH
COMMAND DESCRIPTION
[no] ip ssh server Allows SSH access to the NWA3000-N Series
AP CLI. The
no command disables SSH access
to the NWA3000-N Series AP CLI.
[no] ip ssh server cert certificate_name Sets a certificate whose corresponding private
key is to be used to identify the NWA3000-N
Series AP for SSH connections. The
no
command resets the certificate used by the SSH
server to the factory default (
default).
certificate_name: The name of the
certificate. You can use up to 31 alphanumeric
and ;‘~!@#$%^&()_+[]{}’,.=-
characters.
[no] ip ssh server port <1..65535> Sets the SSH service port number. The
no
command resets the SSH service port number to
the factory default (22).
[no] ip ssh server v1 Enables remote management using SSH v1. The
no command stops the NWA3000-N Series AP
from using SSH v1.
show ip ssh server status Displays SSH settings.
