![Zyxel NWA3550-N [31/152] Status](/views2/1169192/page31/bg1f.png)
NWA3000-N Series CLI Reference Guide
31
CHAPTER 4
Status
This chapter explains some commands you can use to display information about the
NWA3000-N Series AP’s current operational state.
Here are examples of the commands that display the CPU and disk utilization.
Table 8 Status Show Commands
COMMAND DESCRIPTION
show boot status Displays details about the NWA3000-N Series AP’s startup state.
show cpu status Displays the CPU utilization.
show disk Displays the disk utilization.
show extension-slot Displays the status of the extension card slot and the USB ports and the names of any
connected devices.
show led status Displays the status of each LED on the NWA3000-N Series AP.
show mac Displays the NWA3000-N Series AP’s MAC address.
show mem status Displays what percentage of the NWA3000-N Series AP’s memory is currently being
used.
show ram-size Displays the size of the NWA3000-N Series AP’s on-board RAM.
show serial-number Displays the serial number of this NWA3000-N Series AP.
show socket listen Displays the NWA3000-N Series AP’s listening ports
show socket open Displays the ports that are open on the NWA3000-N Series AP.
show system uptime Displays how long the NWA3000-N Series AP has been running since it last restarted or
was turned on.
show version Displays the NWA3000-N Series AP’s model, firmware and build information.
Router# show cpu status
CPU utilization: 0 %
CPU utilization for 1 min: 0 %
CPU utilization for 5 min: 0 %
Router# show disk
No. Disk Size(MB) Usage
===========================================================================
1 image 65 82%
2 onboard flash 154 36%
