AWK-6222 User’s Manual Software Installation/Configuration

5-4

5. The Console login screen will appear. Log into the RS-232 console with the login name

(default: admin) and password (default: root, if no new password is set).

6. The AWK-6222’s device information and Main Menu will be displayed. Please follow the

description on screen and select the administration option you wish to perform.

NOTE

To modify the appearance of the PComm Terminal Emulator window, select Edit Æ Font and

then choose the desired formatting options.
