Click&Go V2 Click&Go V2 Developing Process
3-6
Analog Output Mode Selection
The only model that currently provides analog output channels is ioLogik E2240, which provides both voltage
and current output.
Mode Available
Number of Analog
Output Channels
Mode Selection:
Voltage
Mode Selection:
Current
ioLogik E2240 2 0 to 10 V 4 to 20 mA
When logged in as an administrator, double click on a channel in the I/O Configuration tab to configure that
channel’s settings. A window will open with configuration options for that channel. Each AO channel will be
configured to output either voltage or current according to the Range Settings.
