Click&Go V2 Click&Go Examples and Applications
4-13
Applications_2
The ioLogik E2262 provides temperature monitoring, alarm and shutdown control for a pumping system.
Project Background
In
the pumping system of a tank farm, bearings of a pump motor
always burn out after
the motor runs non-stop for a period of time
. The
downtime and damage
caused by overheated bearings raise
maintenance costs and reduce output
. Extra expenses are not only
incurred from repairing or replacing the bearings, but paying the
engineers for overtime as well.
Application Requirements
In order to keep the motors running smoothly and continuously, the tank farm requested a remote monitoring
and control system to monitor the temperature of the motors. When the temperature rises too high, the
front-end controller must shut down the motor and restart it after the temperature cools back down to an
appropriate level. In addition, the front-end controller must send out a notification e-mail to the central site and
field engineer’s blackberry when the motors shut down and recover.
Moxa Solution
The ioLogik E2262 Active Ethernet I/O server is designed for mixed I/O applications. The 8 TC (thermocouple)
inputs can connect 9 types of TC sensors (mV mode included) and the 4 built-in digital inputs can connect to
multiple outputs such as alarms, buzzers, and lights. With the Click&Go local control logic, users can easily
program the ioLogik E2262 to control the pumps, generate alarms, send status updates to the control center,
or deliver e-mail notifications. Click&Go logic also allows the ioLogik to seamlessly integrate and manage
temperature monitoring, output control, and alarms.
Solution Benefits
The ioLogik E2262 provided the pumping system with the following benefits:
• A controller with both TC temperature sensor inputs and digital output channels
• 100 meters of TC sensor cable length with 2 built-in CJC
• Click&Go’s easy IF-THEN-ELSE style control logic, which eliminates the need for a PLC or RTU
• Alarm messaging can be generated via TCP, UDP, or SNMP trap, or e-mail
• Compact size and cost-effectiveness
Additional Features
The ioLogik E2262 is also equipped with the following additional features:
• Scheduling feature sets start and shutdown times for the pump motors
• Moxa’s Active OPC Server to connect ioLogik devices to the most popular SCADA systems
