Click&Go V2 Internal Registers - Modbus/TCP
A-2
ioLogik E2240, E2242, E2260 and E22262
4xxxx Read/Write Registers (Functions 3, 6, 16)
Reference Address Data Type Description
40337 0x0150 1 word Internal Register 00 Value
40338 0x0151 1 word Internal Register 01 Value
40339 0x0152 1 word Internal Register 02 Value
40340 0x0153 1 word Internal Register 03 Value
40341 0x0154 1 word Internal Register 04 Value
40342 0x0155 1 word Internal Register 05 Value
40343 0x0156 1 word Internal Register 06 Value
40344 0x0157 1 word Internal Register 07 Value
40345 0x0158 1 word Internal Register 08 Value
40346 0x0159 1 word Internal Register 09 Value
40347 0x015A 1 word Internal Register 10 Value
40348 0x015B 1 word Internal Register 11 Value
40349 0x015C 1 word Internal Register 12 Value
40350 0x015D 1 word Internal Register 13 Value
40351 0x015E 1 word Internal Register 14 Value
40352 0x015F 1 word Internal Register 15 Value
40353 0x0160 1 word Internal Register 16 Value
40354 0x0161 1 word Internal Register 17 Value
40355 0x0162 1 word Internal Register 18 Value
40356 0x0163 1 word Internal Register 19 Value
40357 0x0164 1 word Internal Register 20 Value
40358 0x0165 1 word Internal Register 21 Value
40359 0x0166 1 word Internal Register 22 Value
40360 0x0167 1 word Internal Register 23 Value
