Moxa ioLogik E2210 [89/90] Iologik e2210 e2212 and e2214
![Moxa ioLogik E2212-T [89/90] Iologik e2210 e2212 and e2214](/views2/1201328/page89/bg59.png)
A
A. Internal Registers - Modbus/TCP
ioLogik E2210, E2212 and E2214
4xxxx Read/Write Registers (Functions 3, 6, 16)
Reference Address Data Type Description
40377 0x0178 1 word Internal Register 00 Value
40378 0x0179 1 word Internal Register 01 Value
40379 0x017A 1 word Internal Register 02 Value
40380 0x017B 1 word Internal Register 03 Value
40381 0x017C 1 word Internal Register 04 Value
40382 0x017D 1 word Internal Register 05 Value
40383 0x017E 1 word Internal Register 06 Value
40384 0x017F 1 word Internal Register 07 Value
40385 0x0180 1 word Internal Register 08 Value
40386 0x0181 1 word Internal Register 09 Value
40387 0x0182 1 word Internal Register 10 Value
40388 0x0183 1 word Internal Register 11 Value
40389 0x0184 1 word Internal Register 12 Value
40390 0x0185 1 word Internal Register 13 Value
40391 0x0186 1 word Internal Register 14 Value
40392 0x0187 1 word Internal Register 15 Value
40393 0x0188 1 word Internal Register 16 Value
40394 0x0189 1 word Internal Register 17 Value
40395 0x018A 1 word Internal Register 18 Value
40396 0x018B 1 word Internal Register 19 Value
40397 0x018C 1 word Internal Register 20 Value
40398 0x018D 1 word Internal Register 21 Value
40399 0x018E 1 word Internal Register 22 Value
40400 0x018F 1 word Internal Register 23 Value
