Click&Go V2 Click&Go V2 Developing Process
3-9
Testing the I/O Channels
Each I/O channel can be tested or monitored individually. When logged in as an administrator, double click on
a channel in the I/O Configuration tab to configure that channel’s settings. A window will open with
configuration options for that channel. Tests can be done by opening the channel’s configuration window and
selecting the Test tab.
In the Test tab, you can see how a channel’s status affects or is affected by the attached device. For output
channels, you can set the on/off status, start and stop a pulse, or output a voltage or current. For input
channels, you can monitor the attached device’s on/off status, counter, or input voltage/current.
Define Global Variables
Global Variables include the settings of “Internal Register Settings”, “Timer Settings”, “SNMP Trap
Server”, “E-Mail Server” and “Active Message Server”. If these functions are going to be used in Click&Go
V2 rule-set, default configuration must first be set in the Global Variable Menu Bar.
Active Message Server
E-Mail Server
SNMP Trap Server
Timer Settings
Internal Register Settings
