Vitek VT-1835 B [7/48] English

E N G L I S H

– Do not dry the filter (25) and other removable

parts with a hairdryer.

• Install the filter (25) back to its place and close

the dust bin (11) upper lid.

• Set the dust bin lid so that the arrow on the lid

(23) ↓ matches the mark

on the removable

flask (27) and turn the lid till the mark

• Install the dust bin (11) back to its place.

Removing and cleaning the float (28)

There is a float (28) on the inner surface of the

removable flask (27), that enables you to control

the water level in the flask. Provide that the float

moves freely and is not dirty.

• In case the float (28) doesn’t move freely,

press the button of the float holder (29) and

remove the float (28) (pic. 9).

• Wash the holder (29) and the float (28) under

running water.

• Wash the float hollow in the removable flask (27).

• Install the float (28) and the holder (29) to their

place.

Notes:

– Never use the vacuum cleaner without the

correctly installed float (28) and holder (29),

as this can damage the unit.

Removing and cleaning the outlet НЕРА filter

(16)

• Open the grid (17) by pressing the lock and

pulling the grid (17) towards yourself.

• Remove the outlet HEPA filter (16), wash it un-

der slightly warm water jet, if necessary. Dry

the filter thoroughly before installing it back to

its place (pic. 10).

• Install the HEPA filter (16) back to its place and

close the grid (17).

Attention! Provide that the HEPA filter (16) is

always clean, because cleanness of air leaving

the vacuum cleaner depends on it; clean the

HEPA filter (16) no less than 3-4 times a year,

and more often at severe obstruction.

Notes:

– Do not wash the HEPA filter (16) in a dishwash-

ing machine.

– Before installing the HEPA filter (16) make sure

that it is dry.

– Do not dry the HEPA filter (16) with a hairdryer.

Cleaning of the turbo brush

Clean the rotating brush as it becomes dirty. You

can easily remove threads or long hair wound up

around the brush, by cutting them with scissors

preliminarily; be careful not to damage the bristles

of the brush.

Vacuum cleaner body

– Clean the vacuum cleaner body with a soft,

slightly damp cloth and then wipe it dry.

– Do not immerse the body of the vacuum

cleaner, the power cord and the power plug of

the unit into water or other liquids. Provide that

no water gets inside the vacuum cleaner body.

– Never use solvents or abrasives to clean the

surface of the vacuum cleaner.

Delivery set

1. Vacuum cleaner (with the filters and the dust

bin installed) – 1 pc.

2. Flexible hose – 1 pc.

3. Universal brush with «carpet/floor» switch –

1 pc.

4. Turbo brush – 1 pc.

5. Liquid collecting brush – 1 pc.

6. Crevice nozzle – 1 pc.

7. Small brush – 1 pc.

8. Instruction manual – 1 pc.

Technical specifications

Power supply: 220-240 V ~ 50 Hz

Power consumption: 1800 W

Suction power: 400 W

Dust bin capacity 2 l

The manufacturer preserves the right to change

design and specifications of the unit without a

preliminary notification.

Unit operating life is 5 years

Guarantee

Details regarding guarantee conditions can be ob-

tained from the dealer from whom the appliance

was purchased. The bill of sale or receipt must be

produced when making any claim under the terms

of this guarantee.

This product conforms to the EMC-

Requirements as laid down by the

Council Directive 2004/108/ЕС and to

the Low Vol tage Regulation (2006/95/

ЕС)

VT-1835_IM.indd 7 26.02.2014 9:38:00
