ABB RLON-01 [19/82] Compatibility
![ABB RLON-01 [19/82] Compatibility](/views2/1556908/page19/bg13.png)
Overview
19
Compatibility
The RLON-01 is compatible with
• ACS550 and ACH550
• ACS800 Standard Application Program ASXR7010 or later.
Delivery check
The option package for the RLON-01 L
ONWORKS
®
Adapter module
contains
•L
ONWORKS
®
Adapter module, type RLON-01
• two screws (M3x10)
• this manual.
ABB Drive
LONWORKS
®
nodes
Status LEDs
(For descriptions see
chapter Fault tracing)
Service pin
Terminal block X1 for the
bus cable connection
(For descriptions see
chapter Electrical
installation)
ABB Drive
X1
Fixing screw
(frame)
(GND)
The construction of the LONWORKS
®
network and the module layout of
the RLON-01 Adapter module.
