Drive parameter settings
35
ACS800 parameter settings
Parameter Setting Function
99.02 APPLICATION
MACRO*
Set to PID if
corresponding
network variables are
to be used
Enables the updates of nciPidGain,
nciPidIntTime and nciPidDerTime.
99.04 MOTOR CTRL
MODE
Motor control mode
DTC; SCALAR
Initialises RLON-01 operation
mode.
99.07 MOTOR NOM
FREQ*
Motor nominal
frequency
Initialises the nciNmlFreq value.
99.08 MOTOR NOM
SPEED*
Motor nominal speed Initialises the nciNmlSpeed value.
This value corresponds to
nviSpeedStpt value 100% (of
nominal speed or frequency).
10.01 EXT1 STRT/
STP/DIR
COMM MODULE Enables network control of the
drive.
10.03 DIRECTION REQUEST Enables change of direction.
11.02 EXT1/EXT2
SEL
11.09 Enables the change of external
control location via pointer
parameter 11.09 EXT1/EXT2 SEL
PTR.
11.03 EXT REF1
SELECT
COMM MODULE Enables network reference setting.
11.09 EXT1/EXT2
PTR
+.009.006.11 Determines the parameter 11.09 to
point to signal 9.06 DS MCW bit 11,
which carries the nviExt1Ext2Ctrl
command.
16.01 RUN ENABLE COMM MODULE Enables the run enable command
via the network.
16.04 FAULT RESET
SEL
COMM MODULE Enables the fault reset command
via the network.
