Communication
38
Node object
Input network variable
NviObjRequest
Definition:
Network input SNVT_obj_request nviObjRequest
Explanation:
Enables control commands and updates from network. The status
of the node is reported in nvoObjStatus.
Valid range:
Commands not listed above will be reported as invalid_request in
nvoObjStatus.
Object request Function
RQ_UPDATE_STATUS Updates nvoObjStatus.
RQ_CLEAR_STATUS Clears nvoObjStatus.
RQ_CLEAR_ALARM Resets fault in the drive.
RQ_REPORT_MASK Reports supported requests in
nvoObjStatus.
RQ_NORMAL Sets object to default state. (the normal
request)
RQ_DISABLE Stops the drive with the selected stop mode
and disables the operation and object.
RQ_ENABLE Enables the drive for operation and
enables the object.
Node Object
Mandatory
Network
Variables
nv1
nviObjRequest
SNVT_obj_request
nv2
nvoObjStatus
SNVT_obj_status
