Communication
40
Variable speed motor drive object
Variable Speed Motor Drive: 6010
Mandatory
network variables
nv1
nviDrvSpeedStpt
SNVT_switch
Optional
network
variables
nv4
nvoDrvSpeed
SNVT_lev_percent
nv2
nviDrvSpeedScale
SNVT_lev_percent
nv3
nvoDrvCurnt
SNVT_amp
nv5
nvoDrvVolt
SNVT_volt
nv6
nvoDrvPwr
SNVT_power_kilo
nv7
nvoDrvRunHours
SNVT_time_hour
nv100
nviResetFault
SNVT_switch
nv101
nviEmergOverride
SNVT_hvac_emerg
nv103
nviDigOutput2
1)
SNVT_switch
nv102
nviDigOutput1
1)
SNVT_switch
nv105
nvoSpeedActRpm
SNVT_count_inc
nv107
nvoDrvTemp
SNVT_temp_p
nv108
nvoFreqAct
SNVT_freq_hz
Manufacturer
defined
network
variables
Manufacturer defined configuration properties
ncABB2 - nciPidGain ncABB7 - nciStopLevel
ncABB3 - nciPidIntTime ncABB9 - nciParValue
ncABB4 - nciPidDerTime ncABB10 - nciParRead
ncABB6 - nciStopMode ncABB11 - nciParWrite
Configuration properties
nc17 - nciLocation
nc50 - nciMaxSpeed (mandatory)
nc53 - nciMinSpeed (mandatory)
nc48 - nciRcvHrtBt
nc49 - nciSndHrtBt (mandatory)
nc52 - nciMinOutTm
nc158 - nciNmlSpeed (mandatory)
nc159 - nciNmlFreq (mandatory)
nc160 - nciRampUpTm (mandatory)
nc161 - nciRampDownTm (mandatory)
nc162 - nciDrvSpeedScale
nv109
nvoDrvStatus
SNVT_count
nv110
nvoRunning
SNVT_switch
nv111
nvoFaulted
SNVT_switch
nv112
nvoPIDact
SNVT_lev_precent
nv113
nvoEmergOvrStat
SNVT_hvac_emerg
nv114
nvoDigInput1
SNVT_switch
nv115
nvoDigInput2
SNVT_switch
nv116
nvoAnlgInput
1)
SNVT_lev_precent
nv117
nvoParValue
SNVT_count_inc
1)
ACx550 only
2)
Not supported with all RLON-01
and drive versions
nv118
nviDigOutput
2)
SNVT_state
nv119
nviDigExt1Ext2Stat
2)
SNVT_switch
nv120
nvoDigIOStat
2)
SNVT_state
nv121
nvoExt1Ext2Stat
2)
SNVT_switch
nv122
nvoLocRemStat
2)
SNVT_switch
nv123
nvoLastFault
2)
SNVT_count
