Network variables
54
NvoDrvStatus
Definition:
Network output SNVT_state nvoDrvStatus
Explanation:
Indicates the status of the drive.
Valid range:
Bit Name Value Description
0 FWD 1 The motor is rotating in forward direction.
1 REV 1 The motor is rotating in reverse direction.
2 NETCTRL 1 The LonWorks network is selected as the active control source.
3 NETREF 1 The LonWorks network is selected as the active reference source.
4 RTSO 1 Inverter power section is ready to be switched on.
5 FAULT 1 The inverter has a fault.
6 ALARM 1 The inverter has an alarm.
7 REF 1 The motor is running at reference speed / frequency.
8FORN 1 Not in use.
9 ZERO SPEED 1 The motor is running inside the zero speed window.
10 LIMIT 1 The speed, frequency or torque is out of its limits.
11 ACC 1 The motor is accelerating.
12 DEC 1 The motor is decelerating.
13 Vendor Specific 1 1 Not in use
14 Vendor Specific 2 1 Not in use
15 Vendor Specific 3 1 Not in use
