Drive parameter settings
36
*If one of the drive parameter values marked with * not using the
corresponding configuration network variable is changed, the
RLON-01 needs to be re-initialised in order to update it's value.
For example, if the stop mode parameter is changed with the
control panel, the RLON-01 needs to be either rebooted or
temporarily disabled for the RLON-01 to read the updated value
from the drive. The same applies if one of the marked parameters
using the nciParValue configuration parameter is changed.
20.01 MINIMUM
SPEED*
Minimum motor
speed. Only in DTC
mode.
Initialises nciMinSpeed value.
20.02 MAXIMUM
SPEED*
Maximum motor
speed. Only in DTC
mode.
Initialises nciMaxSpeed value.
20.07 MINIMUM
FREQ*
Minimum output
frequency. Only in
SCALAR mode.
Initialises nciMinSpeed value.
20.08 MAXIMUM
FREQ*
Maximum output
frequency (in
SCALAR MODE
ONLY)
Initialises nciMaxSpeed value.
22.02 ACCEL TIME1 Acceleration time Initialises nciRampUpTm value.
22.03 DECEL TIME1 Deceleration time Initialises nciRampDownTm value.
40.01 PID GAIN* PID gain Initialises nciPidGain value.
40.02 PID INTEG
TIME*
PID integration time Initialises nciPidIntTime value.
40.03 PID DERIV
TIME*
PID derivation time Initialises nciPidDerTime value.
98.02 COMM
MODULE LINK
FIELDBUS Enables fieldbus communication
with the drive.
98.07 COMM
PROFILE
GENERIC Enables control of the drive via the
Variable Speed Motor Drive object.
Parameter Setting Function
